Kingston Fury Renegade G5 4 TB PCIe 5.0 NVMe SSD Review (2026)

Name: Kingston Fury Renegade G5 4 TB
Brand: Kingston
SKU: kingston-pcie-5-fury-renegade-g5-4-tb
Rating: 4.3 (66 reviews)

Posted on June 22, 2026 by Raymond Chen

The Kingston Fury Renegade G5 4 TB is the flagship of Kingston's first PCIe 5.0 lineup, pairing Silicon Motion's cooler SM2508 controller with Kioxia 218-layer TLC for 14,800 MB/s reads and full-speed 14,000 MB/s writes.

Kingston Fury Renegade G5 4 TB PCIe 5.0 NVMe SSD Review

Controller & Memory

The Kingston Fury Renegade G5 4 TB is the top capacity of Kingston's first PCIe 5.0 lineup, and it's the SKU that delivers the family's full headline spec. Inside is Silicon Motion's SM2508, an eight-channel controller built on a 4 nm process with four Arm Cortex-R8 cores and a low-power Cortex-M0 core. The defining benefit over first-wave Gen5 is thermals: SM2508 runs markedly cooler than Phison's E26, which means the G5 can sustain peak throughput under a passive heatsink where E26 boards often throttle on the same test bench. Feeding the controller is Kioxia 218-layer BiCS8 3D TLC NAND and an LPDDR4 DRAM cache scaled to the 4 TB die stack.

The 4 TB sits at the top of a three-SKU family and posts the family's highest rated numbers. Kingston sells the Renegade G5 in 1 TB, 2 TB and 4 TB, with speeds stepping up by capacity. The 4 TB is rated at 14,800 MB/s sequential read and 14,000 MB/s sequential write, against 14,700 / 14,000 MB/s on the 2 TB and 14,200 / 11,000 MB/s on the 1 TB. Endurance scales linearly with capacity: 4,000 TBW here versus 2,000 TBW on the 2 TB and 1,000 TBW on the 1 TB. Like the 2 TB, the 4 TB uses a double-sided PCB, which is fine for desktop M.2 mounts and the PS5 bay but can foul very slim laptop slots that only accept single-sided sticks.

The 4 TB is the right pick for a specific buyer: someone who wants one drive to hold the OS, a large working set of creative files (4K video, raw photo libraries, game-development assets), and a sizable game library without juggling multiple volumes. The capacity matters at Gen5 because the larger SLC cache holds peak write speeds for tens of gigabytes before settling to native TLC rates, which makes a real difference for sustained writes that would saturate a smaller drive's cache within seconds. Plan for a heatsink; Kingston ships a bare stick, and while the SM2508 is efficient, sustained PCIe 5.0 throughput still wants passive cooling. Direct rivals include the Crucial T705 4 TB, the WD Black SN8100N 4 TB (same SM2508 platform), and the Corsair MP700 Pro 4 TB.

Storage Comparisons:

Best 4 TB SSD Best PCIe 5.0 SSD Best Deal of 1 TB SSDs NVME

Fury Renegade G5 Performance & Benchmarks

Kingston rates the Fury Renegade G5 4 TB at 14,800 MB/s sequential read and 14,000 MB/s sequential write over PCIe 5.0 x4, with up to 2,200,000 random read IOPS and 2,200,000 random write IOPS. These are the headline numbers for the family: roughly double the sequential throughput of a flagship PCIe 4.0 drive like the Samsung 990 Pro, and enough that DirectStorage-enabled titles can stream assets without the storage layer being a meaningful bottleneck.

Performance comparison

Kingston Fury Renegade G5 4 TB vs M.2 5.0 peers

Switch between sequential throughput and random IOPS to see how this drive stacks up against other M.2 5.0 SSDs in our database. The highlighted bar is the drive on this page — click any other bar to open that drive.

Corsair MP700 Pro XT 1 TB: 14,900 MB/s read, 14,200 MB/s write
Corsair MP700 Pro XT 2 TB: 14,900 MB/s read, 14,500 MB/s write
Corsair MP700 Pro XT 4 TB: 14,900 MB/s read, 14,400 MB/s write
Crucial T710 1 TB: 14,900 MB/s read, 13,800 MB/s write
Kingston Fury Renegade G5 4 TB (this drive): 14,800 MB/s read, 14,000 MB/s write

The 4 TB's advantage over its smaller siblings is partly speed and partly cache depth. As the flagship it posts the family's highest read figure, though the gap to the 2 TB's 14,700 MB/s is within run-to-run variance and not user-perceptible. The larger benefit is the SLC cache: more NAND dies means a larger pseudo-cache region, so sustained writes for video projects, large archive extractions, or game library migrations hold peak speed for tens of gigabytes before settling to native TLC rates. Independent reviewers including TechPowerUp and StorageReview report the SM2508 platform setting fresh records for sequential 1M read and write throughput alongside class-leading random read IOPS. The 4 nm controller's thermal efficiency matters most here because the 4 TB pulls the highest peak power of the family (Kingston rates maximum power at 9.5 W versus 7.0 W on the 2 TB), so cool running translates to less throttling under sustained Gen5 load than E26 platforms at the same capacity.

Kingston Fury Renegade G5 vs Competitors

See how the Fury Renegade G5 stacks up against other M.2 5.0 drives in our database:

Compare with rival drives:

Corsair MP700 Pro XT 4 TB Acer Predator GM9 4 TB ADATA Mars 980 Blade 4 TB

Endurance, TBW & Warranty

Kingston rates the Fury Renegade G5 4 TB at 4,000 TBW (terabytes written) over a five-year limited warranty, whichever comes first. That follows the family's linear 1,000 TBW-per-TB pattern: 1,000 TBW on the 1 TB and 2,000 TBW on the 2 TB. At a typical consumer write workload of 20 to 50 GB per day, the 4 TB reaches its endurance ceiling in roughly 219 to 548 years, so the warranty term, not the endurance rating, is the binding limit for every realistic buyer. Even heavy creative workloads (hundreds of GB per day of 4K video writes) take decades to approach the ceiling. Kingston ties coverage to the Kingston SSD Manager "Percentage Used" SMART attribute, so remaining endurance is visible without guesswork. The five-year term matches the rest of the G5 family and equals or beats rivals like the Crucial T705 and Corsair MP700 Pro. MTBF is rated at 2,000,000 hours, the standard figure for enterprise-adjacent consumer NVMe drives; treat it as a population statistic, not a per-unit lifespan. RMA goes through Kingston or the retailer with serial-based validation.

Kingston Fury Renegade G5 4 TB Specifications

Category	Value
Capacity [?]	4 TB
Interface [?]	M.2 5.0
Controller [?]	Silicon Motion SM2508
Memory type [?]	Toshiba 218-L TLC
DRAM [?]	Yes
Read speed (MB/s) [?]	14800
Write speed (MB/s) [?]	14000
Read IOPS [?]	2200000
Write IOPS [?]	2200000
Endurance (TBW) [?]	4000
MTBF (million hours) [?]	2000000
Warranty (years) [?]	5

Verdict: Is the Fury Renegade G5 Worth It in 2026?

Buy the Kingston Fury Renegade G5 4 TB if you want a single drive that holds your OS, your full creative working set, and your game library at Gen5 speed without compromise on capacity, thermals, or endurance. Skip it if your use case is a pure boot drive, where the 1 TB delivers the same real-world game load times for less, or if your board only supports PCIe 4.0, in which case a high-end Gen4 drive like the Samsung 990 Pro matches perceptible load times at a fraction of the cost per gigabyte. The closest direct rival is the Crucial T705 4 TB, which posts slightly higher peak write numbers on paper but runs hotter on the older E26 platform. For content creators, game library hoarders, and anyone who wants the drive to outlast the rest of the build, the 4 TB G5 is the highest-capacity, lowest-compromise Gen5 pick in the lineup.

+ Pros

14,800 MB/s sequential reads on PCIe 5.0
Full-speed 14,000 MB/s writes at 4 TB
Cool-running SM2508 4 nm controller
4,000 TBW endurance rating
Five-year limited warranty
Large SLC cache sustains long writes

- Cons

Premium pricing per gigabyte over 2 TB
Double-sided PCB fouls some slim slots
No heatsink included in the box
Peak power draw higher than smaller capacities

4.3 / 5 · 66 votes

Buy this or similar SSD Storage:

Samsung 980 Pro 2 TB

-57% $165
List Price: $379.99

Buy on Amazon

INLAND Performance Plus 1 TB

$79.99

Buy on Amazon

Silicon Power 512GB NVMe SSD

$42.97

Buy on Amazon

Video Review

Kingston's First Gen5 SSD - Fury Renegade G5 Review

Frequently Asked Questions

Yes. The 4 TB G5 hits 14,800 MB/s sequential reads and 2,200,000 random read IOPS, well above what current DirectStorage-enabled titles need to stream assets without stutter. Real-world game load times are essentially indistinguishable from any other Gen5 drive at this tier, and the SM2508 controller runs cool enough that thermal throttling isn't a concern under a passive heatsink. The 4 TB capacity is large enough to hold a boot partition plus a substantial library of AAA games, which matters because moving games between drives to manage space is the most common reason a 1 TB or 2 TB feels cramped.

Yes, with a heatsink. Sony requires M.2 NVMe SSDs up to 110 x 25 x 11.25 mm including heatsink, PCIe 4.0 or faster, and recommends at least 5,500 MB/s sequential read. The G5 is M.2 2280 and far exceeds the read speed requirement at 14,800 MB/s. Sony doesn't list individual models on its compatibility page, but the G5 meets every published criterion. The 4 TB uses a double-sided PCB, which is fine for the PS5 bay as long as the heatsink fits within Sony's 11.25 mm height limit; most low-profile third-party aluminium heatsinks clear it. You must add a heatsink since Kingston ships the bare stick.

Yes. The 4 TB pairs the Silicon Motion SM2508 controller with an LPDDR4 DRAM cache, sized appropriately for the 4 TB flash address space, that holds the flash translation layer mapping table. DRAM caching matters for sustained random I/O, low write amplification under mixed workloads, and consistent latency when the FTL is large; at 4 TB the FTL is genuinely large, so a DRAM-backed mapping table is more important here than on smaller capacities. It's one of the reasons the G5 outperforms DRAM-less HMB designs in random read benchmarks and under sustained mixed I/O.

The 4 TB capacity is rated at 4,000 TBW (terabytes written), following the family's linear 1,000 TBW-per-TB pattern (1,000 on the 1 TB, 2,000 on the 2 TB). At a typical consumer write workload of 20 to 50 GB per day, the 4 TB reaches its endurance ceiling in roughly 219 to 548 years, so the five-year warranty, not the endurance rating, is the binding limit for every realistic buyer. Even heavy creative workloads moving hundreds of GB per day take decades to approach the ceiling. Kingston exposes remaining endurance via the Kingston SSD Manager "Percentage Used" SMART attribute.

A passive heatsink is strongly recommended, even though the SM2508 controller is more efficient than first-wave Phison E26 Gen5 drives. The G5 ships as a bare stick without a stock heatsink, so you need either a motherboard-integrated M.2 shield or a third-party cooler. The 4 TB pulls the highest peak power of the family (Kingston rates maximum power at 9.5 W versus 7.0 W on the 2 TB), so cooling matters most at this capacity. Without any heatsink the drive will throttle within minutes under a sustained sequential write benchmark. A basic aluminium heatsink is enough; active cooling is overkill for the SM2508 platform.

Slightly on reads, identical on writes. The 4 TB is rated at 14,800 MB/s sequential read and 14,000 MB/s sequential write, against the 2 TB's 14,700 MB/s read and the 1 TB's 14,200 MB/s read and 11,000 MB/s write. The read gaps are small and within run-to-run variance for the 2 TB; the meaningful difference is the 1 TB's lower write speed, which reflects fewer NAND dies to parallelise across. The 4 TB's larger practical advantage is the bigger SLC cache, which lets sustained writes hold peak speed for tens of gigabytes before settling to native TLC rates.

Both target the top tier of PCIe 5.0 drives, but they use different controllers. The Corsair MP700 Pro uses Phison's E26 platform, while the G5 uses Silicon Motion's newer SM2508 built on a 4 nm process. The practical difference is thermals: independent reviewers consistently report the G5 runs cooler and throttles less under sustained load than E26-based Gen5 drives, while the MP700 Pro can post slightly higher peak write numbers in synthetic benchmarks. Both carry five-year warranties and comparable TBW at matching capacities. Choose the G5 if thermals and quiet operation matter (small-form-factor builds, passive-cooling setups) and the MP700 Pro if peak synthetic write numbers are the priority.
