Corsair MP600 Pro NH 8TB: Flagship Bulk Storage (2026)
The Corsair MP600 Pro NH 8TB is a DRAM-equipped PCIe 4.0 flagship rated for 7,000 MB/s reads, offering the line's largest capacity without a bundled heatsink.
Controller & Memory
The MP600 Pro NH 8TB runs an 8-channel Phison PS5018-E18 controller with Micron 176-layer 3D TLC NAND and onboard DRAM, putting it in Corsair's DRAM-equipped flagship tier rather than the budget or DRAM-less lines. The "NH" designation stands for no heatsink: Corsair sells the same core platform with a heatsink as the MP600 Pro XT, but the NH variant is built bare so it fits thin laptops, small-form-factor cases, and PS5 consoles without clearance issues.
Corsair sells the MP600 Pro NH in 500GB, 1TB, 2TB, 4TB, and 8TB capacities, and 8TB sits at the top of the line for both capacity and endurance. Random-read IOPS is rated slightly lower at 8TB (950,000) than on the 2TB and 4TB (1,000,000), likely a reflection of how the controller manages the larger number of denser NAND packages needed to reach this capacity, while write IOPS holds at the line's peak 1,200,000.
As a single-sided M.2 2280 drive with no bundled heatsink, the MP600 Pro NH 8TB competes against other large-capacity DRAM-equipped PCIe 4.0 flagships and against Corsair's own DRAM-less MP600 Elite line, which tops out at 4TB and doesn't reach this drive's capacity ceiling at all. For buyers who specifically need 8TB in a single M.2 slot, the pool of direct rivals is smaller than at 1TB-4TB, where nearly every major SSD brand competes.
Storage Comparisons:
MP600 Pro NH Performance & Benchmarks
The 8TB MP600 Pro NH is rated for 7,000 MB/s sequential reads and 6,500 MB/s sequential writes, with random performance rated at 950,000 IOPS reading and 1,200,000 IOPS writing. As a DRAM-equipped drive, it holds random-access performance more consistently under mixed workloads than DRAM-less rivals, since the onboard DRAM chip handles the flash translation layer's mapping tables directly rather than borrowing system RAM, which matters more at this capacity given the larger address space to track.
Corsair MP600 Pro NH 8 TB vs M.2 4.0 x 4 peers
Switch between sequential throughput and random IOPS to see how this drive stacks up against other M.2 4.0 x 4 SSDs in our database. The highlighted bar is the drive on this page — click any other bar to open that drive.
- Patriot Viper PV593 1 TB: 14,500 MB/s read, 14,000 MB/s write
- Patriot Viper PV593 2 TB: 14,500 MB/s read, 14,000 MB/s write
- Patriot Viper PV593 4 TB: 14,500 MB/s read, 14,000 MB/s write
- Patriot Viper PV573 2 TB: 14,000 MB/s read, 12,000 MB/s write
- Corsair MP600 Pro NH 8 TB (this drive): 7,000 MB/s read, 6,500 MB/s write
Like other TLC drives, the MP600 Pro NH leans on an SLC write cache to hit its peak write number; once a sustained transfer outruns that cache, throughput drops toward native TLC write speed. At 8TB, large sustained transfers, like archiving a full media library or bulk footage from a video project, are more likely in practice than on smaller capacities, and more likely to eventually outrun the cache. Corsair doesn't publish the exact cache size for this capacity. For PS5 use, this drive's 7,000 MB/s read rating comfortably clears Sony's 5,500 MB/s minimum, and the no-heatsink design is specifically built to fit the PS5's storage expansion slot.
Corsair MP600 Pro NH vs Competitors
See how the MP600 Pro NH stacks up against other M.2 4.0 x 4 drives in our database:
Compare with rival drives:
Endurance, TBW & Warranty
The 8TB MP600 Pro NH carries a 6,000 TBW endurance rating, the highest in the line, and a full 5-year warranty. At a realistic consumer workload of 30 to 50GB written per day, 6,000 TBW takes roughly 330 to 550 years to exhaust, far beyond the 5-year warranty window and comfortably covering even heavy professional content-creation workloads. Corsair's official spec sheet for this capacity does not publish an MTBF figure, so treat any population-level reliability number from third-party listings as an estimate rather than a Corsair-confirmed spec. The 5-year warranty and 6,000 TBW rating make this one of the more generous endurance profiles available at this capacity tier.
Corsair MP600 Pro NH 8 TB Specifications
| Category | Value |
|---|---|
| Capacity [?] | 8 TB |
| Interface [?] | M.2 4.0 x 4 |
| Controller [?] | Phison PS5018-E18 8 Channel |
| Memory type [?] | Micron 176-L TLC |
| DRAM [?] | Yes |
| Read speed (MB/s) [?] | 7000 |
| Write speed (MB/s) [?] | 6500 |
| Read IOPS [?] | 950000 |
| Write IOPS [?] | 1200000 |
| Endurance (TBW) [?] | 6000 |
| MTBF (million hours) [?] | 1800000 |
| Warranty (years) [?] | 5 |
Verdict: Is the MP600 Pro NH Worth It in 2026?
The MP600 Pro NH 8TB suits buyers who want the largest practical DRAM-equipped flagship capacity without a bundled heatsink, including video professionals, large media archivists, and PS5 owners who want a single drive covering an entire library. Buyers who don't need this much capacity should look at the 2TB or 4TB in the same line, or Corsair's own DRAM-less MP600 Elite for a lower-cost alternative at smaller capacities. Rival 8TB flagships from other brands exist but are less common than at 1TB-4TB, so direct comparisons are thinner than at smaller capacities. For maximum bulk capacity backed by a full 5-year warranty, the MP600 Pro NH 8TB's 6,000 TBW endurance is among the strongest available at this size.
+ Pros
- 7,000 MB/s reads at flagship-tier speed
- 6,000 TBW endurance, highest in the line
- Onboard DRAM for consistent random performance
- Full 5-year warranty
- Largest capacity in the MP600 Pro NH line
- No heatsink needed for PS5 or thin laptops
- Cons
- Random read IOPS lower than the 2TB and 4TB
- No published MTBF figure from Corsair
- Write speed tapers once SLC cache fills
- Fewer direct 8TB rivals to compare against
- Costs more than Corsair's own DRAM-less Elite line
