MSI Spatium M570 Pro 2 TB: MSI's Earlier Gen5 Flagship (2026)

Posted on July 01, 2026 by Raymond Chen

The MSI Spatium M570 Pro 2 TB FROZR is the flagship capacity of MSI's earlier cooled PCIe 5.0 line, pairing the lineup's peak 12,400 MB/s reads with a bundled tower heatsink.

MSI Spatium M570 Pro 2 TB: MSI's Earlier Gen5 Flagship

Controller & Memory

The MSI Spatium M570 Pro 2 TB is the flagship capacity of MSI's Spatium M570 Pro FROZR, a PCIe 5.0 NVMe drive announced in December 2023 and sold in 1 TB, 2 TB and 4 TB sizes. It is the predecessor to the newer Spatium M580 FROZR, and like the M580 every M570 Pro ships with MSI's FROZR cooler pre-installed in the box: a passive tower heatsink with no fan that makes the drive unusual among Gen5 models, which normally leave M.2 cooling to the buyer. The cooler is there because the hardware runs hot, as the Phison E26 controller and Micron NAND platform draw up to 11.5 watts on the 2 TB under load.

Under the metal is an M.2 2280 drive built on the eight-channel Phison PS5026-E26 controller, Micron 3D TLC NAND and an LPDDR4 DRAM cache, the same platform used by the Crucial T700, Adata Legend 970 and Aorus Gen5 7000s. As the flagship capacity, the 2 TB carries the peak numbers of the M570 Pro line: it is rated at 12,400 MB/s sequential read and 11,800 MB/s write, against 11,700 and 9,500 MB/s on the value 1 TB. Endurance scales with capacity, so the 2 TB carries 1,400 TBW against 700 TBW on the 1 TB and 3,000 TBW on the 4 TB, while the whole line shares a 5-year warranty, a 1.6 million hour MTBF and AES 256 with TCG Opal encryption.

The trade-off is physical and generational. The FROZR tower cooler is tall and blocks adjacent M.2 slots on some motherboards, and club386 notes the drive will not fit a PlayStation 5 without manually removing the heatsink, so the M570 Pro FROZR suits a desktop build with a free, well-spaced PCIe 5.0 M.2 slot rather than a laptop or console. It is also an earlier Gen5 design that MSI has since superseded with the faster M580 FROZR. Direct rivals are the Crucial T700, Corsair MP700, Adata Legend 970 and Aorus Gen5 on the same Phison E26 platform; the M570 Pro FROZR's case is the included cooler and a 5-year warranty at a lower price than the newer M580.

Storage Comparisons:

Top 2 TB SSDs Best PCIe 5.0 SSD Best Deal of 1 TB SSDs NVME

Spatium M570 Pro Performance & Benchmarks

The 2 TB MSI Spatium M570 Pro FROZR is rated at 12,400 MB/s sequential read and 11,800 MB/s sequential write over its PCIe 5.0 x4 interface. These are the peak numbers of the M570 Pro line: the 1 TB model drops to 11,700 MB/s read and 9,500 MB/s write, so the 2 TB is the capacity to buy for maximum speed in this family. Random performance is strong on the Phison E26 platform, with the line rated around 1.5 million random IOPS.

Performance comparison

MSI Spatium M570 Pro 2 TB vs M.2 5.0 peers

Switch between sequential throughput and random IOPS to see how this drive stacks up against other M.2 5.0 SSDs in our database. The highlighted bar is the drive on this page — click any other bar to open that drive.

Corsair MP700 Pro XT 1 TB: 14,900 MB/s read, 14,200 MB/s write
Corsair MP700 Pro XT 2 TB: 14,900 MB/s read, 14,500 MB/s write
Corsair MP700 Pro XT 4 TB: 14,900 MB/s read, 14,400 MB/s write
Crucial T710 1 TB: 14,900 MB/s read, 13,800 MB/s write
MSI Spatium M570 Pro 2 TB (this drive): 12,400 MB/s read, 11,800 MB/s write

For real-world use, 12,400 MB/s is deep into PCIe 5.0 territory and well beyond any PCIe 4.0 drive, so the bandwidth shows up in the workflows that actually saturate a Gen5 link: fast in-game asset streaming and DirectStorage titles, large file transfers, and OS responsiveness. Reviewers frame the M570 Pro FROZR as a fast, hot-running Phison E26 design that needs the bundled FROZR cooler to sustain its numbers, since the platform draws up to 11.5 watts and will throttle without adequate thermal management.

The honest caveat is sustained writes. Like all TLC NVMe drives, the M570 Pro writes into a fast SLC cache first, then drops to a lower direct-TLC rate once the cache fills. The 2 TB carries a larger cache than the 1 TB, so under a long contiguous write such as a video render it holds full speed longer before slowing to the direct-TLC rate. For boot, applications and a large game library the cache is effectively never exhausted, which is exactly the workload the 2 TB is built for.

MSI Spatium M570 Pro vs Competitors

See how the Spatium M570 Pro stacks up against other M.2 5.0 drives in our database:

Compare with rival drives:

Corsair MP700 PRO 2 TB Crucial T700 2 TB Galax HOF 50 2 TB

Endurance, TBW & Warranty

The 2 TB MSI Spatium M570 Pro FROZR carries a rated endurance of 1,400 TBW (terabytes written), double the 700 TBW of the 1 TB and below the 3,000 TBW of the 4 TB. MSI covers the drive for 5 years, with coverage ending at whichever threshold comes first, the 5-year term or 1,400 TBW of cumulative writes. The 5-year term is the standard retail coverage for this tier and is longer than the 3-year OEM warranties on some competing Gen5 drives.

For almost all buyers the time limit, not the endurance limit, is what binds. At a typical 20 GB of writes per day, exhausting 1,400 TBW would take around 192 years; at a heavy 100 GB per day it is still roughly 38 years. Only users writing several hundred gigabytes every single day would approach the TBW ceiling inside the 5-year window. The drive is rated at 1,600,000 hours MTBF, a population-reliability statistic rather than a per-unit life expectancy.

MSI Spatium M570 Pro 2 TB Specifications

Category	Value
Capacity [?]	2 TB
Interface [?]	M.2 5.0
Controller [?]	Phison PS5026-E26 8 Channels
Memory type [?]	Micron 232-L TLC
DRAM [?]	Yes
Read speed (MB/s) [?]	12400
Write speed (MB/s) [?]	11800
Read IOPS [?]	1300000
Write IOPS [?]	1500000
Endurance (TBW) [?]	1400
MTBF (million hours) [?]	1600000
Warranty (years) [?]	5

Verdict: Is the Spatium M570 Pro Worth It in 2026?

The MSI Spatium M570 Pro 2 TB FROZR is the drive to buy if you want the peak of MSI's earlier cooled Gen5 lineup with a bundled heatsink, without paying for the newer M580. It pairs the family's fastest rated speed, 12,400 MB/s reads and 11,800 MB/s writes, with double the 1 TB's endurance at 1,400 TBW and a larger SLC cache that holds sustained writes at full speed for longer, all under the pre-installed FROZR tower cooler.

Step down to the 1 TB if you want the same cooler and platform for less and can live with 11,700/9,500 MB/s and 700 TBW, or move to the newer MSI M580 FROZR if you want a meaningfully faster successor on the same cooled platform, since the M580 reaches 14,600 MB/s reads. Skip the M570 Pro FROZR if your build cannot fit the tall tower cooler, or if you do not specifically need Gen5, where a high-end PCIe 4.0 drive delivers most of the real-world benefit for less. For a desktop with a free PCIe 5.0 slot and a preference for an all-in-one cooled drive at a lower price than the M580, the 2 TB M570 Pro FROZR is the sweet spot of the line.

+ Pros

Bundled FROZR passive tower heatsink included
PCIe 5.0 with 12,400 MB/s peak sequential reads
Phison E26 with Micron 3D TLC and DRAM cache
1,400 TBW endurance, double the 1 TB model
5-year warranty with 1.6M-hour MTBF
AES 256 and TCG Opal encryption on board

- Cons

Superseded by the faster MSI M580 FROZR
Tall FROZR cooler blocks adjacent M.2 slots
Hot-running Phison E26 draws up to 11.5 watts
Peak Gen5 speed is wasted on most current games
Backward compatibility caps at PCIe 4.0 speeds

3.9 / 5 · 12 votes

Buy this or similar SSD Storage:

Samsung 980 Pro 2 TB

-57% $165
List Price: $379.99

Buy on Amazon

INLAND Performance Plus 1 TB

$79.99

Buy on Amazon

Silicon Power 512GB NVMe SSD

$42.97

Buy on Amazon

Video Review

MSI SPATIUM M570 PRO PCIe 5.0 NVMe M.2 FROZR Unboxing and Installation

Frequently Asked Questions

Yes. The M570 Pro FROZR's PCIe 5.0 bandwidth, 12,400 MB/s sequential read on the 2 TB and roughly 1.5 million random IOPS, is well beyond what current games demand, so load times and asset streaming are effectively ceiling-bound and the drive is ready for DirectStorage titles as they arrive. The bundled FROZR cooler handles Gen5 thermals without throttling. The 2 TB is the flagship of the M570 Pro line for speed and holds an operating system plus a large game library with room to spare, which is the real reason to pick it over the slower 1 TB.

Yes, and that is its defining feature. The M570 Pro FROZR ships with MSI's FROZR cooler pre-installed in the box: a passive tower heatsink with no fan. Most PCIe 5.0 drives leave M.2 cooling to the buyer, because the Phison E26 platform runs hot and draws up to 11.5 watts; MSI solves that at the factory. The trade-off is that the tall tower cooler blocks adjacent M.2 slots on some motherboards, and club386 notes it will not fit a PlayStation 5 without manually removing the heatsink, so check your board or console clearance before buying.

Not practically. Sony requires an M.2 NVMe SSD with sequential reads above 5,500 MB/s, which the M570 Pro exceeds, but the PS5's expansion slot is wired for PCIe 4.0, so a PCIe 5.0 drive runs there at roughly half its rated bandwidth and you would be paying for Gen5 speed the console cannot use. More importantly, the M570 Pro FROZR's tall tower heatsink will not fit under the PS5's M.2 cover without being removed, which defeats the point of buying the cooled variant. A cheaper, lower-profile PCIe 4.0 drive is the sensible PS5 choice.

Yes. The M570 Pro pairs its Phison E26 controller with an LPDDR4 DRAM cache, confirmed by club386's teardown, which found 4 GB of LPDDR4 DRAM on the 2 TB board for buffering. That holds the drive's logical-to-physical address mapping table in dedicated memory rather than borrowing system RAM through the HMB mechanism used by DRAM-less designs, giving more consistent random-access latency under mixed workloads. It is the same DRAM-equipped platform the drive shares with the Crucial T700 and its other Gen5 rivals.

The 2 TB MSI Spatium M570 Pro FROZR is rated for 1,400 TBW (terabytes written), double the 700 TBW of the 1 TB and below the 3,000 TBW of the 4 TB. Coverage ends at whichever limit comes first: 5 years or 1,400 TBW. In practice the time limit binds first for nearly everyone, since at 20 GB of writes per day reaching 1,400 TBW would take about 192 years, and even at a heavy 100 GB per day it is around 38 years. Only sustained, very write-heavy daily workloads would approach the endurance ceiling inside the 5-year term.

The M570 Pro is the earlier design and the M580 FROZR is its newer, faster successor in the same cooled Gen5 family. Both use the Phison E26 controller with Micron TLC and a DRAM cache, and both ship with a FROZR tower heatsink pre-installed, so the hardware and the cooling concept are closely related. The difference is speed: the M580 reaches 14,600 MB/s reads and 12,700 MB/s writes, against the M570 Pro's 12,400 and 11,800 MB/s. If peak Gen5 throughput matters, the M580 is the stronger pick; if you want the included cooler for less, the M570 Pro remains a solid value Gen5 entry.

Yes, in rated sequential speed. The 2 TB M570 Pro FROZR is rated at 12,400 MB/s read and 11,800 MB/s write, against 11,700 MB/s read and 9,500 MB/s write on the 1 TB, so the 2 TB is the flagship capacity of the line. The 2 TB also carries double the endurance at 1,400 TBW versus 700 TBW on the 1 TB, and a larger SLC cache that exhausts later under sustained writes. For maximum peak speed and write headroom, the 2 TB is the stronger pick.
