MSI Spatium M570 Pro 1 TB: MSI's Earlier Cooled Gen5 Entry (2026)

Posted on July 01, 2026 by Raymond Chen

The MSI Spatium M570 Pro 1 TB FROZR is the value entry of MSI's earlier cooled PCIe 5.0 line, rated at 11,700 MB/s reads with a bundled tower heatsink.

MSI Spatium M570 Pro 1 TB: MSI's Earlier Cooled Gen5 Entry

Controller & Memory

The MSI Spatium M570 Pro 1 TB is the value capacity of MSI's Spatium M570 Pro FROZR, a PCIe 5.0 NVMe drive announced in December 2023 and sold in 1 TB, 2 TB and 4 TB sizes. It is the predecessor to the newer Spatium M580 FROZR, and like the M580 every M570 Pro ships with MSI's FROZR cooler pre-installed in the box: a passive tower heatsink with no fan that makes the drive unusual among Gen5 models, which normally leave M.2 cooling to the buyer. The cooler is there because the hardware runs hot, as the Phison E26 controller and Micron NAND platform draw around 11 watts on the 1 TB under load.

Inside the metal is an M.2 2280 drive built on the eight-channel Phison PS5026-E26 controller, Micron 3D TLC NAND and an LPDDR4 DRAM cache, the same platform used by the Crucial T700, Adata Legend 970 and Aorus Gen5 7000s. As the value capacity, the 1 TB carries the lowest numbers in the M570 Pro line: it is rated at 11,700 MB/s sequential read and 9,500 MB/s write, against 12,400 and 11,800 MB/s on the 2 TB and 4 TB. Endurance scales the same way, so the 1 TB carries 700 TBW against 1,400 TBW on the 2 TB and 3,000 TBW on the 4 TB, while the whole line shares a 5-year warranty, a 1.6 million hour MTBF and AES 256 with TCG Opal encryption.

The trade-off is physical and generational. The FROZR tower cooler is tall and blocks adjacent M.2 slots on some motherboards, and club386 notes the drive will not fit a PlayStation 5 without manually removing the heatsink, so the M570 Pro FROZR suits a desktop build with a free, well-spaced PCIe 5.0 M.2 slot rather than a laptop or console. It is also an earlier Gen5 design that MSI has since superseded with the faster M580 FROZR. Direct rivals are the Crucial T700, Corsair MP700, Adata Legend 970 and Aorus Gen5 on the same Phison E26 platform; the M570 Pro FROZR's case is the included cooler and a 5-year warranty at the value end of the Gen5 market.

Storage Comparisons:

Best Deal of 1 TB SSDs NVME Best PCIe 5.0 SSD Top 2 TB SSDs

Spatium M570 Pro Performance & Benchmarks

The 1 TB MSI Spatium M570 Pro FROZR is rated at 11,700 MB/s sequential read and 9,500 MB/s sequential write over its PCIe 5.0 x4 interface. These are the lowest numbers in the M570 Pro line: the 2 TB and 4 TB models reach 12,400 MB/s read and 11,800 MB/s write, so the 1 TB is the slowest capacity rather than the flagship. Random IOPS are not published by MSI for this drive, but the platform is rated up to around 1.3 million random read and 1.5 million random write IOPS, consistent with the Phison E26 design it shares with its rivals.

Performance comparison

MSI Spatium M570 Pro 1 TB vs M.2 5.0 peers

Switch between sequential throughput and random IOPS to see how this drive stacks up against other M.2 5.0 SSDs in our database. The highlighted bar is the drive on this page — click any other bar to open that drive.

Corsair MP700 Pro XT 1 TB: 14,900 MB/s read, 14,200 MB/s write
Corsair MP700 Pro XT 2 TB: 14,900 MB/s read, 14,500 MB/s write
Corsair MP700 Pro XT 4 TB: 14,900 MB/s read, 14,400 MB/s write
Crucial T710 1 TB: 14,900 MB/s read, 13,800 MB/s write
MSI Spatium M570 Pro 1 TB (this drive): 11,700 MB/s read, 9,500 MB/s write

For real-world use, 11,700 MB/s is still deep into PCIe 5.0 territory and comfortably beyond any PCIe 4.0 drive, so the bandwidth shows up in the workflows that actually saturate a Gen5 link: fast in-game asset streaming and DirectStorage titles, large file transfers, and OS responsiveness. Reviewers frame the M570 Pro FROZR as a fast, hot-running Phison E26 design that needs the bundled FROZR cooler to sustain its numbers, since the platform draws around 11 watts and will throttle without adequate thermal management.

The honest caveat is sustained writes. Like all TLC NVMe drives, the M570 Pro writes into a fast SLC cache first, then drops to a lower direct-TLC rate once the cache fills. The 1 TB carries the smallest cache in the lineup, so under a long contiguous write such as a video render the slowdown to direct-TLC speed arrives sooner than on the 2 TB or 4 TB. For boot, applications and a typical game library the cache is effectively never exhausted, so everyday performance stays close to the rated figures.

MSI Spatium M570 Pro vs Competitors

See how the Spatium M570 Pro stacks up against other M.2 5.0 drives in our database:

Compare with rival drives:

Corsair MP700 PRO 1 TB Gigabyte Aorus Gen5 12000 1 TB Lexar NM1090 1 TB

Endurance, TBW & Warranty

The 1 TB MSI Spatium M570 Pro FROZR carries a rated endurance of 700 TBW (terabytes written), the lowest in a lineup that scales to 1,400 TBW on the 2 TB and 3,000 TBW on the 4 TB. MSI covers the drive for 5 years, with coverage ending at whichever threshold comes first, the 5-year term or 700 TBW of cumulative writes. The 5-year term is the standard retail coverage for this tier and is longer than the 3-year OEM warranties on some competing Gen5 drives.

For almost all buyers the time limit, not the endurance limit, is what binds. At a typical 20 GB of writes per day, exhausting 700 TBW would take around 96 years; at a heavy 100 GB per day it is still roughly 19 years. Only users writing several hundred gigabytes every single day would approach the TBW ceiling inside the 5-year window, and a 1 TB client drive is rarely asked to do that. The drive is rated at 1,600,000 hours MTBF, a population-reliability statistic rather than a per-unit life expectancy.

MSI Spatium M570 Pro 1 TB Specifications

Category	Value
Capacity [?]	1 TB
Interface [?]	M.2 5.0
Controller [?]	Phison PS5026-E26 8 Channels
Memory type [?]	Micron 232-L TLC
DRAM [?]	Yes
Read speed (MB/s) [?]	11700
Write speed (MB/s) [?]	9500
Read IOPS [?]	1300000
Write IOPS [?]	1500000
Endurance (TBW) [?]	700
MTBF (million hours) [?]	1600000
Warranty (years) [?]	5

Verdict: Is the Spatium M570 Pro Worth It in 2026?

The MSI Spatium M570 Pro 1 TB FROZR is the drive to buy if you want a PCIe 5.0 SSD with a bundled heatsink at the value end of MSI's Gen5 lineup and you do not need the absolute fastest peak speed. The included FROZR tower cooler, the proven Phison E26 plus Micron TLC plus DRAM platform and the 5-year warranty make it a self-contained Gen5 entry, and the 1 TB is the cheapest way into that package at 11,700 MB/s reads and 700 TBW.

Step up to the M570 Pro 2 TB if you want the line's peak 12,400/11,800 MB/s and double the endurance at 1,400 TBW, or move to the newer MSI M580 FROZR if you want a meaningfully faster successor on the same cooled platform, since the M580 reaches 14,600 MB/s reads. Skip the M570 Pro FROZR if your build cannot fit the tall tower cooler, or if you do not specifically need Gen5, where a high-end PCIe 4.0 drive delivers most of the real-world benefit for less. For a desktop with a free PCIe 5.0 slot and a preference for an all-in-one cooled drive at the value tier, the M570 Pro FROZR 1 TB remains a sensible, well-warranted choice.

+ Pros

Bundled FROZR passive tower heatsink included
PCIe 5.0 with 11,700 MB/s sequential reads
Phison E26 with Micron 3D TLC and DRAM cache
5-year warranty with 1.6M-hour MTBF
AES 256 and TCG Opal encryption on board
Self-contained cooling out of the box

- Cons

Slowest M570 Pro capacity at 9,500 MB/s writes
Superseded by the faster MSI M580 FROZR
Tall FROZR cooler blocks adjacent M.2 slots
Hot-running Phison E26 draws around 11 watts
700 TBW is the lowest endurance in the line

4 / 5 · 112 votes

Buy this or similar SSD Storage:

Samsung 980 Pro 2 TB

-57% $165
List Price: $379.99

Buy on Amazon

INLAND Performance Plus 1 TB

$79.99

Buy on Amazon

Silicon Power 512GB NVMe SSD

$42.97

Buy on Amazon

Video Review

SPATIUM M570 PRO FROZR - Unboxing | MSI

Frequently Asked Questions

Yes. The M570 Pro FROZR's PCIe 5.0 bandwidth, 11,700 MB/s sequential read on the 1 TB and up to around 1.5 million random IOPS, is well beyond what current games demand, so load times and asset streaming are effectively ceiling-bound and the drive is ready for DirectStorage titles as they arrive. The bundled FROZR cooler means you do not have to worry about Gen5 thermal throttling mid-session. The 1 TB capacity holds an operating system plus a respectable game library, though buyers who install many large AAA titles may prefer the 2 TB for the room and the higher 12,400 MB/s peak.

Yes, and that is its defining feature. The M570 Pro FROZR ships with MSI's FROZR cooler pre-installed in the box: a passive tower heatsink with no fan. Most PCIe 5.0 drives leave M.2 cooling to the buyer, because the Phison E26 platform runs hot and draws around 11 watts; MSI solves that at the factory. The trade-off is that the tall tower cooler blocks adjacent M.2 slots on some motherboards, and club386 notes it will not fit a PlayStation 5 without manually removing the heatsink, so check your board or console clearance before buying.

Not practically. Sony requires an M.2 NVMe SSD with sequential reads above 5,500 MB/s, which the M570 Pro exceeds, but the PS5's expansion slot is wired for PCIe 4.0, so a PCIe 5.0 drive runs there at roughly half its rated bandwidth and you would be paying for Gen5 speed the console cannot use. More importantly, the M570 Pro FROZR's tall tower heatsink will not fit under the PS5's M.2 cover without being removed, which defeats the point of buying the cooled variant. A cheaper, lower-profile PCIe 4.0 drive is the sensible PS5 choice.

Yes. The M570 Pro pairs its Phison E26 controller with an LPDDR4 DRAM cache that holds the drive's logical-to-physical address mapping table in dedicated memory, rather than borrowing system RAM through the HMB mechanism used by DRAM-less designs. club386's teardown confirms the LPDDR4 DRAM buffer on the PCB. That gives more consistent random-access latency under mixed workloads, which matters for an operating-system drive, and it is the same DRAM-equipped platform the drive shares with the Crucial T700 and its other Gen5 rivals.

The 1 TB MSI Spatium M570 Pro FROZR is rated for 700 TBW (terabytes written), the lowest in a lineup that scales to 1,400 TBW on the 2 TB and 3,000 TBW on the 4 TB. Coverage ends at whichever limit comes first: 5 years or 700 TBW. In practice the time limit binds first for nearly everyone, since at 20 GB of writes per day reaching 700 TBW would take about 96 years, and even at a heavy 100 GB per day it is around 19 years. Only sustained, very write-heavy daily workloads would approach the endurance ceiling inside the 5-year term.

The M570 Pro is the earlier design and the M580 FROZR is its newer, faster successor in the same cooled Gen5 family. Both use the Phison E26 controller with Micron TLC and a DRAM cache, and both ship with a FROZR tower heatsink pre-installed, so the hardware and the cooling concept are closely related. The difference is speed: the M580 reaches 14,600 MB/s reads and 12,700 MB/s writes, against the M570 Pro's 12,400 and 11,800 MB/s on its 2 TB and 4 TB. If peak Gen5 throughput matters, the M580 is the stronger pick; if you want the included cooler for less, the M570 Pro remains a solid value Gen5 entry.

Yes, in rated sequential speed. The 1 TB M570 Pro FROZR is rated at 11,700 MB/s read and 9,500 MB/s write, against 12,400 MB/s read and 11,800 MB/s write on the 2 TB and 4 TB, so the 1 TB is the slowest capacity in the line. The 1 TB also carries the lowest endurance at 700 TBW versus 1,400 TBW on the 2 TB, and a smaller SLC cache that exhausts sooner under sustained writes. For everyday boot and gaming workloads the difference is modest; for maximum peak speed and write headroom, the 2 TB is the stronger pick.
